Lumex SELECT Series User Manual

LS200-INS-LAB-RevB17 13
STATIC function
MODE Button Pressure
Adjustment
Knob
MODE LED (STATIC / ALTERNATE)
Pump Front Panel
Press and hold the MODE button, shown above, for one second to select STATIC mode, and
adjust the pressure adjustment knob, also shown above, to achieve the maximum patient
comfort. In STATIC mode, the system provides True Low Air Loss therapy through cell micro
vents.
Perform a pressure hand check by placing your hand under the patient buttocks between cells
and bottom of mattress. The patient should have at least 1
1
/2 in. (4 cm) of clearance between
the buttocks and the bottom of the mattress.
ALTERNATE function
Press and hold the MODE button, shown above, for one second to select ALTERNATE mode
and enable the two-one alternating function. Alternating time is pre-set and not adjustable. The
cycle time, shown below, is twelve minutes:
1) four minutes deate “A” cells
2) two minutes STATIC
3) four minutes deate “B” cells
4) two minutes STATIC
* Info: The first three cells on the mattress head end ALWAYS remain in STATIC mode.
