Lumiax MT2010 - Structure & Characteristics of MT2075;2010;3075; Structure & Characteristics of MT 010;4010;4015

③
④
⑧⑨ ⑦
MENU
OK
4.2 Characteristics of MT2075/2010/3075 Structure &
①Heat Sink
—dissipate controller heat
②Plastic Case
—Internal protection
③LCD
— Display settings and operating status,
system parameters
④Key: MENU、OK
—Set and view the operating parameters
⑤RJ11 interface
—Connecting monitoring devices
⑥Temperature Sensor Port
—Collect temperature information,
Temperature compensation.
⑦ Load Terminals
—Connected load.
⑧Battery Terminals
—Connect the battery.
⑨Solar module terminals
—Connected solar modules.
②
⑤
⑥
①
