Luminator BLACKCOMB LB4 Series User Manual

14|Page
BLACKCOMB
4.1
Controllers
LB4
Series
LBH4
Series
Simplisc in operaon, these systems feature a tri-colour
LED that indicang system status and a 4-digit display to in-
dicate lamp life remaining. Pressing the buon will change
the display to indicate total running me. When the UV lamp
is on and within its operang age, the LED will be green.
When the UV lamp is not on or the lamp life has expired,
the LED will be illuminated red and an audible buzzer will be
sounding. To remedy this condion, the UV lamp must be
replaced with a new genuine LUMINOR UV lamp.
BLACKCOMB
5.1
& BLACKCOMB
6.1
Controllers
LB5 / LB6
Series
LBH5 / LBH6
Series
A full colour LCD screen provides the user with a detailed
descripon of the system’s performance in addion to pro-
viding any applicable fault messages and system diagnoscs.
The controllers used in both the BLACKCOMB
5.1
and BLACK-
COMB
6.1
are idencal. The dierence is that the BLACK-
COMB
6.1
series of products includes a UV intensity monitor.
All BLACKCOMB
5.1
and BLACKCOMB
6.1
controllers include an
“innite expandability port” located on the right side of the
controller. Simply plug in an oponal UV sensor module into
the expandability port of a BLACKCOMB
5.1
controller and the
system will now monitor the UV intensity of the system!
BLACKCOMB
5.1
& BLACKCOMB
6.1
Power-up Sequence
On start up, the controller will run through a diagnosc start-up and the sequence will be dis-
played as follows on the colour LCD:
Next, the controller checks for and inializes any oponal modules that may be aached to the
system.
Oponal Modules Check
- UV Sensor
- Solenoid
- 4-20 mA
- WIFI
- Remote Alarm
- Flow Meter
OR
