BLACKCOMB Standard Output System Specicaons
LUMINOR EQUIPMENT SPECIFICATIONS
Mul-Use / Residenal systems (standard output lamps)
MODEL
LB4-021
LB5-021
LB6-021
LB4-031
LB5-031
LB6-031
LB4-061
LB5-061
LB6-061
LB4-101
LB5-101
LB6-101
LB4-151
LB5-151
LB6-151
LB4-201
LB5-201
LB6-201
NSF Class A Flow Rate
40mJ/cm
2
@ 70% UVT
(add “A” sux on LB6 models)
1.6 gpm 2.2 gpm 3.4 gpm 6.3 gpm 7.9 gpm N/A
6.1 lpm 8.3 lpm 13 lpm 24 lpm 30 lpm N/A
0.36 m
3
/hr 0.50 m
3
/hr 0.77 m
3
/hr 1.4 m
3
/hr 1.8 m
3
/hr N/A
NSF Class B Flow Rate
16mJ/cm
2
@ 70% UVT
(“B” sux on LB5,LB6 models)
2.9 gpm 5.2 gpm 7.6 gpm 13 gpm 22 gpm N/A
11 lpm 20 lpm 29 lpm 49 lpm 83 lpm N/A
0.66 m
3
/hr 1.2 m
3
/hr 1.7 m
3
/hr 3.0 m
3
/hr 5.0 m
3
/hr N/A
Flow Rate
16mJ/cm
2
@ 95% UVT
3.8 gpm 6.1 gpm 11 gpm 20 gpm 30 gpm 39 gpm
15 lpm 23 lpm 41 lpm 77 lpm 110 lpm 150 lpm
0.87 m
3
/hr 1.4 m
3
/hr 2.5 m
3
/hr 4.6 m
3
/hr 6.8 m
3
/hr 8.9 m
3
/hr
Flow Rate
30mJ/cm
2
@ 95% UVT
2.0 gpm 3 gpm 6 gpm 11 gpm 15 gpm 21 gpm
7.6 lpm 11.4 lpm 22.7 lpm 41 lpm 57 lpm 79 lpm
0.45 m
3
/hr 0.70 m
3
/hr 1.4 m
3
/hr 2.5 m
3
/hr 3.4 m
3
/hr 4.8 m
3
/hr
Flow Rate
40mJ/cm
2
@ 95% UVT
1.6 gpm 2.4 gpm 4.4 gpm 8.3 gpm 12 gpm 16 gpm
6.1 lpm 9.1 lpm 17 lpm 31 lpm 45 lpm 59 lpm
0.36 m
3
/hr 0.50 m
3
/hr 1.0 m
3
/hr 1.9 m
3
/hr 2.7 m
3
/hr 3.6 m
3
/hr
Port Size ½”FNPT ½”MNPT ¾”MNPT ¾”MNPT 1”MNPT 1”MNPT
Electrical 90-265V/50-60Hz. 1A Max.
Plug Type American: NEMA 5-15P
Lamp Power (Was) 8 15 22 39 50 42
Power (Was) 14 20 30 49 62 51
Replacement Lamp RL-210 RL-290 RL-470 RL-820 RL-999 RL-850
Replacement Sleeve RQ-210 RQ-290 RQ-470 RQ-820 RQ-999 RQ-850
Reactor
Dimensions
6.4 x 26.2 cm
(2.5 x 10.3”)
6.4 x 36.4 cm
(2.5 x 14.3”)
6.4 x 54.2 cm
(2.5 x 21.3”)
6.4 x 89.5 cm
(2.5 x 35.2”)
6.4 x 101.6 cm
(2.5 x 40.0”)
8.9 x 91.7 cm
(3.5 x 36.1”)
Chamber Material 304 Stainless Steel, A249 Pressure Rated Tubing
Controller Dimensions 17.2 x 9.2 x 10.2 cm (6.8 x 3.6 x 4”)
Operang Pressure 0.7-10.3 bar (10-150 psi)
Operang Water Temperature 2-40° C (36-104° F)
UV Monitor YES on all “LB6” models. Upgrade available for “LB5” models (NOT available on LB4 models)
Solenoid Output YES (oponal solenoid module (MOD-SOL1) sold separately)
Dry Contacts YES (remote alarm module (MOD-RAM) sold separately)
4-20mA Output YES (4-20mA module (MOD-420) sold separately)
Temperature Mgmt. Valve NA 130031 130032 130033
Cooling Fan NO
OPTIONAL
(130014)
Lamp Change Reminder YES
Lamp Out Indicator YES
Shipping Weight
2.9 kg
(6.3 lbs)
3.6 kg
(7.9 lbs)
4.4 kg
(9.6 lbs)
6.0 kg
(13.2 lbs)
6.5 kg
(14.4 lbs)
8.2 kg
(18.0 lbs)
