Luminator BLACKCOMB LB4 Series User Manual

25|Page
Performance Data Sheet (on all NSF/ANSI Standard 55, Class B Systems)
C US
System Tested and Cered by
NSF Internaonal against CSA
B483.1 and NSF/ANSI 55
for Disinfecon Performance, Class B
Model LB5-03XB
LB5-06XB
LB6-06XB
LB5-10XB
LB6-10XB
LB5-15XB
LB6-15XB
LBH5-05XB
LBH6-06XB
LBH5-10XB
LBH6-10XB
LBH5-15XB
LBH6-15XB
LBH5-25XB
LBH6-25XB
LBH5-40XB
LBH6-40XB
NSF Class B Flow Rate
(16mJ/cm
2
@ 70% UVT)
5.2 gpm
11 lpm
1.2 m
3
/hr
7.6 gpm
29 lpm
1.7 m
3
/hr
13 gpm
49 lpm
3.0 m
3
/hr
22 gpm
83 lpm
5.1 m
3
/hr
5.4 gpm
20 lpm
1.2 m
3
/hr
7.6 gpm
29 lpm
1.7 m
3
/hr
13 gpm
49 lpm
3.0 m
3
/hr
22 gpm
83 lpm
5.1 m
3
/hr
28 gpm
110 lpm
6.4 m
3
/hr
Port Size ½”MNPT ¾”MNPT ¾”MNPT 1” MNPT ½”MNPT ¾”MNPT 1” MNPT 1” MNPT 1” MNPT
Electrical 90-265V/50-60Hz 1A Max 90-265V/50-60Hz 1.5A Max
Operang Pressure 0.7-10.3 bar (10-150 psi)
Operang Water
Temperature
2-40° C (36-104° F)
Note: replace “X” with “1” for all 110V systems with North American NEMA 5-15, 3-wire plug
replace “X” with “2” for all 230V systems with European CEE 7/7, 3-wire plug
replace “X” with “3” for all 230V systems with Brish Standard, BS 1363, 3-wire plug
replace “X” with “4” for all 230V systems with Australian/NewZealand AS/NZ 3112, 3-wire plug
Lamp Life: LB5, LB6 series UV lamps are rated for 9,000 hours of connuous use (one-
year of operaon). LBH5, LBH6 series UV lamps are rated for 10,000 hours of connous use
(approximately 14 months of operaon)
General Operaon and Maintenance: UV lamps are to be replaced on an annual basis. Quartz
sleeves and UV sensors are to be cleaned every 6-12 months and replaced every 5 years.
This Class B system or component conforms to NSF/ANSI 55 for the supplemental bactericidal
treatment disinfected public drinking water or other drinking water that has been tested
and deemed acceptable for human consumpon by the state or local health agency having
jurisdicon. The system is only designed to reduce normally occurring non-pathogenic nuisance
microorganisms. Class B systems are not intended for treatment of contaminated water.
While tesng was performed under standard laboratory condions, actual performance may vary.
The system and installaon shall comply with applicable provincial/state and local regulaons.
