6|Page
Assembly
Unpack the system and ensure all the components are included with the system. Your system is
shipped with the following components:
BLACKCOMB (Standard output lamp systems)
CONTROLLER
GLOW PLUG
(BLACKCOMB
5.1
units only)
UV SENSOR
(BLACKCOMB
6.1
units only)
4.1 SYSTEMS
RC-B4.01
5.1/6.1 SYSTEMS
RC-B56.01
300016 Complete Assembly
310026 Teon Plug
310040 O-Ring
390007 Brass Nut
RS-B2.5 LB4/LB5/LB6 -06, -10, -15
series
RS-B3.5 LB4-20, LB5-20, LB6-20
series
RS-B2.5V NSF Class A series
GLAND NUT
O-RING
SLEEVE SPRING
QUARTZ SLEEVE
REACTOR
UV LAMP
320006
300038
RL-210- “-02” series
RL-290 “-03” series
RL-470 “-06” series
RL-820 “-10” series
RL-850 “-20” series
RL-999 “-15” series
310039
RQ-210 “-02” series
RQ-290 “-03” series
RQ-470 “-06” series
RQ-820 “-10” series
RQ-850 “-20” series
RQ-999 “-15” series
300083 “-02” series
300050 “-03” series
300052 “-06” series
300054 “-10” series
300061 “-15” series
300068 “-20” series
LAMP KEY
