Luminator BLACKCOMB LB4 Series User Manual

23|Page
BLACKCOMB-HO High Output System Specicaons
LUMINOR EQUIPMENT SPECIFICATIONS
Residenal Crossover systems (high output lamps)
MODEL
LBH4-05X
LBH5-05X
LBH6-05X
LBH4-10X
LBH5-10X
LBH6-10X
LBH4-15X
LBH5-15X
LBH6-15X
LBH4-25X
LBH5-25X
LBH6-25X
LBH4-40X
LBH5-40X
LBH6-40X
NSF Class A Flow Rate
40mJ/cm
2
@ 70% UVT
(add “A” sux on LBH6 models)
2.2 gpm 4.0 gpm 5.4 gpm 7.9 gpm 18 gpm
8.3 lpm 15 lpm 20 lpm 30 lpm 68.1 lpm
0.50 m
3
/hr 0.91 m
3
/hr 1.2 m
3
/hr 1.8 m
3
/hr 4.08 m
3
/hr
NSF Class B Flow Rate
16mJ/cm
2
@ 70% UVT
(“B” sux on LBH5,LBH6 models)
5.4 gpm 7.6 gpm 13 gpm 22 gpm 28 gpm
20 lpm 29 lpm 49 lpm 83 lpm 110 lpm
1.2 m
3
/hr 1.7 m
3
/hr 3.0 m
3
/hr 5.0 m
3
/hr 6.4 m
3
/hr
Flow Rate
30mJ/cm
2
@ 95% UVT
5.0 gpm 10 gpm 15 gpm 25 gpm 40 gpm
18.91 lpm 37.9 lpm 57 lpm 95 lpm 151 lpm
1.1 m
3
/hr 2.3 m
3
/hr 3.4 m
3
/hr 5.7m
3
/hr 9.3m
3
/hr
Flow Rate
40mJ/cm
2
@ 95% UVT
3.0 gpm 7.0 gpm 11 gpm 19 gpm 31 gpm
11 lpm 26 lpm 42 lpm 72 lpm 120 lpm
0.68 m
3
/hr 1.6 m
3
/hr 2.5 m
3
/hr 4.3 m
3
/hr 7.0 m
3
/hr
Flow Rate
Hot Water (-HW sux) model
30mJ/cm
2
@ 75% UVT
2.8 gpm 7.0 gpm 9.8 gpm 16 gpm 28 gpm
11 lpm 26 lpm 37 lpm 61 lpm 110 lpm
0.6 m
3
/hr 1.6 m
3
/hr 2.2 m
3
/hr 3.6 m
3
/hr 6.4 m
3
/hr
Flow Rate
Low UVT (-50 sux) model
30mJ/cm
2
@ 50% UVT
1.7 gpm 4.2 gpm 6.1 gpm 10 gpm 17 gpm
6.4 lpm 16 lpm 23 lpm 38 lpm 64 lpm
0.4 m
3
/hr 1.0 m
3
/hr 1.4 m
3
/hr 2.3 m
3
/hr 3.9 m
3
/hr
Flow Rate
TOC (-TOC sux) model
150mJ/cm
2
@ 98% UVT
0.8 gpm 2.0 gpm 2.8 gpm 5.1 gpm 8.0 gpm
3.0 lpm 7.6 lpm 11 lpm 19 lpm 30 lpm
0.2 m
3
/hr 0.5 m
3
/hr 0.6 m
3
/hr 1.1 m
3
/hr 1.8 m
3
/hr
Port Size ¾”MNPT ¾”MNPT 1”MNPT 1”MNPT 1 ½”MNPT
Electrical 90-265V/50-60Hz. 1.5A Max.
Plug Type American: NEMA 5-15P
Lamp Power (Was) 18 34 45 67 101
Power (Was) 20 36 48 72 108
Replacement Lamp RL-210HO RL-330HO RL-420HO RL-600HO RL-950HO
Replacement Sleeve RQ-210 RQ-330 RQ-420 RQ-600 RQ-950
Reactor
Dimensions
8.9 x 29.8 cm
(3.5 x 11.7”)
8.9 x 41.8 cm
(3.5 x 16.5”)
8.9 x 50.8 cm
(3.5 x 20.0”)
8.9 x 68.3 cm
(3.5 x 26.9”)
8.9 x 103.4 cm
(3.5 x 40.7”)
Chamber Material 316L Stainless Steel, A249 Pressure Rated Tubing
Controller Dimensions 21.7 x 10.8 x 10.2 cm (8.6 x 4.2 x 4”)
Operang Pressure 0.7-10.3 bar (10-150 psi)
Operang Water Temperature 2-40° C (36-104° F)
UV Monitor YES on all LBH6 models. Upgrade available for LBH5 models (NOT available on LBH4 models)
Solenoid Output YES (oponal solenoid module (MOD-SOL1) sold separately)
Dry Contacts YES (remote alarm module (MOD-RAM) sold separately)
4-20mA Output YES (4-20mA module (MOD-420) sold separately)
Temperature Mgmt. Valve 130032 130033 130034
Cooling Fan OPTIONAL (130014 sold separately)
Lamp Change Reminder YES
Lamp Out Indicator YES
Shipping Weight
4.4 kg
(9.7 lbs)
5.2 kg
(11.5 lbs)
5.6 kg
(12.9 lbs)
7.0 kg
(15.5 lbs)
9.6 kg
(21.1 lbs)
