Performance Data Sheet (on all NSF/ANSI Standard 55, Class A Systems)
C US
System Tested and Cered by
NSF Internaonal against CSA
B483.1 and NSF/ANSI 55
for Disinfecon Performance, Class A
Model
LB6-02XA
LB6-02A-12V
LB6-02A-24V
LB6-03XA
LB6-03A-12V
LB6-03A-24V
LB6-06XA LB6-10XA LB6-15XA LBH6-05XA LBH6-10XA LBH6-15XA LBH6-25XA LBH6-40XA
NSF Class A Flow Rate
(40mJ/cm
2
@ 70%
UVT)
1.6 gpm
6.1 lpm
0.4 m
3
/hr
2.2 gpm
8.3 lpm
0.5 m
3
/hr
3.4 gpm
13 lpm
0.8 m
3
/hr
6.3 gpm
24 lpm
1.4 m
3
/hr
7.9 gpm
30 lpm
1.8 m
3
/hr
2.2 gpm
8.3 lpm
0.5 m
3
/hr
4.1 gpm
15 lpm
0.9 m
3
/hr
5.4 gpm
20 lpm
1.2 m
3
/hr
7.9 gpm
30 lpm
1.8 m
3
/hr
18 gpm
68.1 lpm
4.08 m
3
/hr
Port Size ½”FNPT ½”MNPT ¾”MNPT ¾”MNPT 1” MNPT ½”MNPT ¾”MNPT 1” MNPT 1” MNPT 1½”MNPT
Electrical 90-265V/50-60Hz 1A Max 90-265V/50-60Hz 1.5A Max
Operang
Pressure
0.7-10.3 bar (10-150 psi)
Operang Water
Temperature
2-40° C (36-104° F)
Note: replace “X” with “1” for all 110V systems with North American NEMA 5-15, 3-wire plug
replace “X” with “2” for all 230V systems with European CEE 7/7, 3-wire plug
replace “X” with “3” for all 230V systems with Brish Standard, BS 1363, 3-wire plug
replace “X” with “4” for all 230V systems with Australian/NewZealand AS/NZ 3112, 3-wire plug
Lamp Life: LB6 series UV lamps are rated for 9,000 hours of connuous use (one-year of
operaon). LBH6 series UV lamps are rated for 10,000 hours of connuous use (approximately
14 months of operaon)
General Operaon and Maintenance: UV lamps are to be replaced on an annual basis. Quartz
sleeves and UV sensors are to be cleaned every 6-12 months and replaced every 5 years.
This Class A system conforms to NSF/ANSI 55 for the disinfecon of microbiologically
contaminated water that meets all other public health standards. The system is not intended to
convert wastewater or raw sewage to drinking water. The system is intended to be installed on
visually clear water.
NSF/ANSI 55 denes wastewater to include human and/or animal body waste, toilet paper, and
any other material intended to be deposited in a receptacle designed to receive urine and/or
feces (blackwaste), and other waste materials deposited in plumbing xtures (greywaste).
If this system is used for the treatment of untreated surface waters or ground water under the
direct inuence of surface water, a device found to be in conformance for cyst reducon under
the appropriate NSF/ANSI standard shall be installed upstream of the system.
While tesng was performed under standard laboratory condions, actual performance may vary.
The systems and installaon shall comply with applicable provincial/state and local regulaons.
