2 Mechanical installation
Figure 2.3 Mounting clearances (see Table 2.6)
Dimensions
of break-
through
BG3 BG4 BG5 BG6
W (width) 75 125 175 250
H (height) 305 305 305 365
Table 2.5 Breakthrough for push-through heat sink (dimensions in mm)
