Lutron Electronics WAC-2019SD - Page 6

Sampling Time Approx. 1 second.
of Display
Data Output RS 232/USB PC computer interface.
* Connect the optional RS232 cable
UPCB-02 will get the RS232 plug.
* Connect the optional USB cable
USB-01 will get the USB plug.
Operating 0 to 50 ℃.
Temperature
Operating Less than 85% R.H.
Humidity
Power Supply * Alkaline or heavy duty DC 1.5 V battery
( UM3, AA ) x 6 PCs, or equivalent.
* DC 9V adapter input. ( AC/DC power
adapter is optional ).
Power Current Normal operation ( w/o SD card save
data :
Approx. DC 22 mA.
When SD card save the data :
Approx. DC 37 mA.
* Depending on the brightness of LCD, the power
consumption will increase approx.
22 ~ 37 mA.
Weight 489 g/1.08 LB.
Dimension 177 x 68 x 45 mm
(7.0 x 2.7x 1.9 inch)
Accessories *
Instruction manual..............................
1 PC
Included *
Hard carrying case ( CA-06 )..................................
1 PC
* Conductivity/TDS probe,
Salt probe, CDPB-04..........................
1 PC
4
