pH PH7, PH4, and PH10, 3 points calibration
Calibration ensure the best linearity and accuracy.
Optional *
PH electrode.......................
PE-03, PE-11, PE-01, PE06HDA
probe and PE-04HD, PE-03K7
accessories *
ATC ( automatic temperature probe ).......................................
TP-07
* pH 7 buffer solution..................... PH-07
* pH 4 buffer solution...................... PH-04
* ORP electrode.............................. ORP-14
Measurement Range Resolution Accuracy
PH 0 to 14 PH 0.01 PH ±(0.02 PH + 2 d)
mV
0 to ±1999 mV
1 mV ±(0.5% + 2 d)
* PH accuracy is based on calibrated meter only.
B. Conductivity
Conductivity probe Optional, Carbon rod electrode for long life.
Function * Conductivity ( uS, mS )
* TDS ( Total Dissolved Solids, PPM )
* Temperature ( ℃,℉)
Temperature Automatic from 0 to 60 ℃ (32 - 140 ℉),
Compensation with temperature compensation factor
variable between 0 to 5.0% per C.
Probe 0 to 60 ℃.
Operating Temp.
Probe Dimension Round, 22 mm Dia. x 120 mm length.
Optional *
Conductivity probe......................................
CDPB-03
probe and * 1.413 mS Conductivity Standard
accessories Solution........................................... CD-14
