““DECK-2’’
Monitor
Terminal
Functions
the
same
as
the
DECK-1
terminal
(32).
Tape
playback
is
possible
if
the
Monitor
Switch
Is
set
at
the
DECK-2/4ch
posi-
tion.
In
case
this
amplifier
is
used
as
a
2-CH
amplifier
for
a
matrix
4-CH
system,
2
of
4
channels
at
the
output
side
of
the
decoder
should
be
connected
to
this
terminal,
and
the
Monitor
Switch
should
be
set
at
the
“deck-2/4ch”
position.
€
Pre
Amplifier
Section
Output
Terminal
(PRE
OUT)
The
whole
output
in
the
pre-amplifier
section,
including
the
tone
controls
and
the
linear
equalizer,
can
be
taken
out
from
this
terminal.
Output
voltage
is
60OmV
against
the
standard
input.
When
using
a
shield
wire,
there
is
no
attenuation
in
the
high
frequencies
because
this
terminal
has
sufficiently
low
output
impedance
of
about
100.
This
terminal
is
for
independent
use
of
the
pre-amplifier,
as
well
as
for
a
mulit-amplifier
system
using
a
channel
divider.
Usually,
this
terminal
and
the
Main-Amplifier
Input
Terminal
(36)
are
coupled
by
a
jumper
cord.
€
Main-Amplifier
Section
Input
Terminal
(MAIN
IN)
The
Main-Amplifier
section
can
function
independently
when
the
signal
is
passed
through
this
terminal.
The
input
sensitivity
is
6OOmvV.
The
variable
Attenuator
(19)
is
inserted
just
after
this
terminal,
permitting
adjustment
of
the
input
level
in
case
of
the
independent
use
of
the
main-amplifier
section.
&
€
Speaker
Terminals
(Main
and
Remote)
The
speaker
systems
should
be
connected
to
these
terminals.
Press
the
cap
of
the
terminal
and
insert
the
bare
speaker
cord
into
the
terminal
hole,
then
release
it.
Firm
connectionis
now
made,
These
terminals
are
coupled
with
the
speaker
switches,
and
the
speaker
switch
must
be
set
at
the
position
corresponding
to
the
terminal
to
which
the
speaker
systems
are
connected.
37
ts
for
the
main
speaker,
and
38
is
for
the
remote
speaker.
The
red
terminal
is
for
(+)
and
the
black
for
(—).
For
further
details,
refer
to
Connection
of
Speakers
(Page
9).
€
DC
Fuses
(RIGHT
and
LEFT
SPEAKER)
Short
circuit
of
the
speaker
terminals
or
extremely
low
impedance
given
by
the
speakers
may
cause
the
DC
fuses
to
blow
out.
In
such
a
case,
ascertain
the
cause
and
correct
it.
Replacement
of
the
fuses
is
done
by
turning
the
fuse
cap
in
the
direction
of
the
arrow
mark
and
inserting
new
fuse.
Be
sure
that
the
mains
cord
is
disconnected.
&
Mains
Fuse
A
5A
fuse
is
inserted
in
the
mains
power
circuit
of
this
amplifier.
If
the
fuse
blows
out,
replace
it,
ascertain
the
cause
and
correct
it.
Replace
the
fuse
by
turning
the
cap
in
the
direction
of
the
arrow
mark.
Be
sure
that
the
mains
power
cord
is
disconnected.
@
Extra
Mains
Outlets
Convenient
for
supplying
mains
power
to
other
equipment
such
2s
AM/FM
tuner
or
record
player.
The
terminals
(41
UNSWITCH-
ED)
are
independent
of
the
mains
switch
of
the
amplifier,
while
the
other
(42
SWITCHED)
is
coupled
with
the
mains
switch.
The
supply
of
the
mains
power
depends
on
the
mains
switch.
The
total
capacity
for
the
UNSWITCHED
(41)
terminals
is
200W.
The
rated
capacity
for
the
SWITCHED
(42)
terminal
is
1OOW.
€
Mains
Connector
One
end
of
the
attached
mains
cord
should
be
connected
to
this
point,
while
the
other
end
with
plug
should
be
connected
to
the
mains
power
supply.
