11
8. Main power button (MAIN POWER)
Turns this unit to the standby state. When this button is set
to ON/STANDBY, the standby indicator on the front panel
lights up to show that this unit turns to the standby state.
When this button is set to OFF, the standby indicator on the
front panel turns off to show that the main power is turned
off.
9. AC inlet (AC IN)
Connects the accessory power cable. The power should be
supplied from a household wall socket.
10. Balanced output terminals/OUTPUTS
(BAL LINE-1, BAL LINE-2)
Use these XLR output terminals to output balanced audio
signals from this unit.
Connect these terminals to the balanced input of an output
device such as a power amplifier using balanced XLR
cables.
Audio signal to output is selected by the output mode
selection button.
There is no difference in quality between BAL LINE-1 and
BAL LINE-2.
Factory default: Unbalanced output (UNBAL)
11. Signal ground (earth terminal)
(SIGNAL GROUND)
The ground terminal is for a device such as analog player
connected to this unit.
This terminal is used to reduce noise when other devices
are connected, but not to be used for grounding for safety.
12. Balanced input terminals/INPUTS
(BAL LINE-1, BAL LINE-2, BAL LINE-3)
XLR connector input terminal to receive balanced audio sig-
nals of a line level.
Connect these terminals to the balanced output of an input
device such as a CD player using balanced XLR cables.
The input audio signal is selected and output with the input
selector.
There is no difference in quality between BAL LINE-1, BAL
LINE-2 and BAL LINE-3.
