30
Block Diagram
FROM INPUT
ATTENUATOR
CONTROL
LECUA-EX (ATTENUATOR + AMP) / EACH CHANNEL
+B3
-B3
LECUA-1
0.5dBx16 STEP
LECUA-2
8dBx12 STEP
TO OUTPU
T
+B1
REG.
LIFES
INPUT
MUTE
-B1
-B2
+B2
DIFF.
AMP
