5. Main power switch (MAIN POWER)
Turns this unit to the standby state.
When this switch is set to ON, the standby indicator on the
front panel lights up to show that this unit turns to the stand-
by state.
When this switch is set to OFF, the standby indicator on the
front panel turns off to show that the main power is turned
off.
6. AC inlet (AC IN)
Connects the accessory power cable.
The power shall be supplied from a household wall socket.
7. Balanced output terminals/OUTPUTS
(BAL LINE-1, BAL LINE-2)
XLR connector output terminal to provide balanced audio
signals from this unit
Connect these terminals to a balanced input of an output
device such as a power amplifier with a balanced cable.
Audio output signals are selected with the output mode se-
lection switch.
BAL LINE-1 and BAL LINE-2 have the same quality.
Factory default output mode: Unbalanced (UNBAL)
8. Signal ground (ground terminal)
(SIGNAL GROUND)
Is a ground terminal for devices to be connected to this unit.
This terminal is used not for safety but for noise reduction
when other devices are connected.
9. Balanced input terminals/INPUTS
(BAL LINE-1, BAL LINE-2, BAL LINE-3)
XLR connector input terminal to receive balanced audio sig-
nals of a line level.
Connect these terminals to a balanced output of an input
device such as a CD player with a balanced cable.
Incoming audio signals are selected with the input selector
and delivered.
BAL LINE-1, BAL LINE-2, and BAL LINE-3 have the same
quality.
