VACUUM TUBE CONTROL AMPLIFIER CL-38uC
9
Before connecting
Before connecting other devices, connect the jack side of the
accessory power cable to the AC inlet of this unit.
Before connection is made, turn off the main power switch
of this unit and the power of all other connected devices to
prevent accidents due to noises generated unexpectedly.
How to connect power supply
Use the accessory power cable and insert the AC plug in the
outlet on the wall in the room where the unit is installed.
How to connect CD player, SACD player,
tuner, or other devices
Connect between the output terminals of a CD player, an
SACD player, a tuner, or other such input devices and any
of LINE-1, LINE-2, LINE-3, and BAL LINE input terminals of
this unit with 2 (R and L) pin-plug cables or balanced cables.
How to connect analog record player
Connect between the output terminals of an analog player
and the PHONO terminals of this unit with 2 (R and L) pin-
plug cables.
For some types of players, the ground wire from the phono
motor or the tone arm should be connected to the ground
terminal of this unit.
The phono equalizer section of this unit supports both the
MM (moving magnet) type cartridge and MC (moving coil)
type cartridge. Select the position of the cartridge selector
(CARTRIDGE) according to the type of the cartridge to be
used. Select an MC position closest to the impedance of the
cartridge to be used by referring to the table below.
CARTRIDGE selector
switch
MM MC
MC IMPEDANCE
switch
– HIGH LOW
Impedance 47 kΩ 100 Ω 30 Ω
The output from an analog record player equipped with a
phono equalizer or from an independent phono equalizer
shall be connected to the line input terminals of this unit.
* During playback using an analog player, hum noises (boon
noise) may be generated regardless of the sound of the
record.
Most of the time, the noise gets mixed from the tone arm
section of the analog player. Check the installed position of
the analog player and rearrange the cabling route if required.
Extra caution is required for the MC cartridge, since the out-
put voltage is low.
* If the sound of the analog player is distorted, it is likely that
the appropriate stylus pressure is not applied to the car-
tridge.
Make adjustment referring to the operating instructions of
the analog player and the cartridge.
If the player is equipped with an anti-skating function, its
adjustment is also required.
* The sound may distorted due to dust adhered to the stylus.
In such a case, clean the stylus carefully with an available
cleaner.
