Features of This Unit
Design of using vacuum tubes for all
amplification circuits
All the amplification circuits consist of vacuum tubes (ECC83S
x 3 pieces and ECC82 x 5 pieces) that are manufactured by
JJ Electronic in Slovak Republic.
Wooden case
A traditional square-shaped wooden case is used.
SRPP structure for all stages
This unit has the structure of SRPP (Shunt Regulated Push
Pull) in all of the phono amplifier, tone control unit, and flat
amplifier to achieve low-impedance transmission.
MC transformer
As many as four MC step-up transformers with high sound
quality are equipped to enjoy genuine analog record play-
back. Independence among MC impedance HIGH, MC
impedance LOW, left, and right respectively has achieved
richly expressive sound that can be produced only by boost-
ing with a transformer.
Balanced input terminal
One line of the balanced type input terminal using the XLR
connector is equipped.
A dedicated balanced input transformer is equipped.
Low cut, monaural
This unit has a low cut switch to suppress woofer fluctuation
caused by a warped analog record and a monaural switch
that is useful at monaural record playback.
Tone control
This unit is also equipped with the bass/treble tone control
function that can select the turnover frequency from three
positions to allow the tone quality to be finely adjusted.
Input/output for recorder
One line of the input/output terminals for recorder that are
connectable to a tape deck or other devices is equipped.
Two lines of line output
This unit has two lines of output terminals that are useful for
wiring in the bi-amplifier structure in which two power amplifi-
ers are used. (two lines always output)
