VACUUM TUBE CONTROL AMPLIFIER CL-38uC
15
Specifications
Total harmonic distortion 0.006 % (1 kHz, 1 V/50 kΩ)
0.06 % (20 Hz to 20 kHz, 1 V/50 kΩ)
Input sensitivity/input impedance PHONO (MM) : 2.0 mV/47 kΩ
PHONO (MC-HIGH) : 0.3 mV/100 Ω
PHONO (MC-LOW) : 0.08 mV/30 Ω
LINE : 190 mV/50 kΩ
MONITOR : 190 mV/50 kΩ
BAL LINE : 190 mV/20 kΩ
S/N ratio PHONO (MM) : 68 dB or more (A weighted, 2.0 mV input)
PHONO (MC-HIGH) : 63 dB or more (A weighted, 0.3 mV input)
PHONO (MC-LOW) : 60 dB or more (A weighted, 0.08 mV input)
LINE : 100 dB or more (A weighted, input short)
BAL LINE : 100 dB or more (A weighted, input short)
Frequency response PHONO (MM) : 20 Hz to 20,000 Hz (±0.5 dB, tone defeat on)
PHONO (MC-HIGH) : 20 Hz to 20,000 Hz (±0.5 dB, tone defeat on)
PHONO (MC-LOW) : 20 Hz to 20,000 Hz (±0.5 dB, tone defeat on)
LINE : 10 Hz - 70,000 Hz (within –3 dB, tone defeat on)
BAL LINE : 10 Hz - 70,000 Hz (within –3 dB, tone defeat on)
Tone control BASS (150 Hz) : ±8.0 dB at 50 Hz
BASS (300 Hz) : ±8.0 dB at 100 Hz
BASS (600 Hz) : ±8.0 dB at 200 Hz
TREBLE (1.5 kHz) : ±8.0 dB at 5 kHz
TREBLE (3 kHz) : ±8.0 dB at 10 kHz
TREBLE (6 kHz) : ±8.0 dB at 20 kHz
Low cut 30 Hz (–6 dB/oct.)
Input
1 line of phono (MM/MC HIGH/MC LOW supported), 3 lines of line,
1 line of balanced line
Recording input/output 1 line for each of recording output and monitor input
Output 2 Lines
Supplied functions
[Front panel]
• Operation switch • Volume control
• Mute button • Balance control
• Input selector • Low frequency selector switch
• Cartridge selector (MM/MC)
• MC impedance switch (HIGH/LOW) • Tone control
• Low cut switch • Mode switch • Monitor switch
[Rear panel]
• Input/output terminals • Signal ground terminal • AC inlet
[Remote control function]
• Sound volume (up/down) • Mute
Circuit SRPP
Vacuum tube used 3×ECC83S, 5×ECC82
Accessories
• Remote control (RA-19) • Power cable
• Terminal protection cap • Owner’s Manual (This document)
• Safety cautions • 2 pieces of “AAA” batteries
Power supply
230 V 〜 (50 Hz)
Power consumption 35 W
Max. external dimensions 440 (W) x 169 (H) x 307 (D) mm
Weight 13.3 kg (main unit)
* Specifications and the appearance are subject to change without notice.
