Luxman M-800A User Manual

13
Rated Continuous output
60W + 60W (8Ω)/ stereo, 120W + 120W (4Ω)/stereo, 240W (2Ω),
480W (1Ω)
240W (8Ω) bridged mode (monaural)
Installed capacity
480W + 480W (1Ω)/ stereo
960W (2Ω)/ bridged mode (monaural)
Input sensitivity
773mV/60W (8Ω), GAIN 29dB
Input impedance
Unbalanced RCA 51KΩ, balanced XLR 67KΩ
Harmonic Distortion
0.009% or less
(1KHz, 60W/8Ω) 0.1% or less (20Hz – 20KHz,
60W/ (8Ω)
Frequency Response
20Hz~20KHz (+0, - 0.2dB) DC~130KHz (+0dB ~ -3dB)
Signal-to-Noise Ratio
117dB (IHF-A)
Damping factor
700/8Ω
Attachment
Front Panel
：
Operation switch, operation indicator and stand-by
indicator, input Change-over Switch, balance indicator
and Bridged indicator, level meter, meter display switch
Rear Panel
：
Mains power switch, Bridge switch (monaural) and input
terminal (RCA and balanced; one of each ), speaker
output (1 systems), signal ground terminal and remote
input terminal, line phase sensor and AC inlet
Accessories
Power cable and remote turn on / off cable
(for use with Luxman control amps C-1000f, C-800, C-600).
Power consumption
492W (rated power) 396W (signal less), 0.9W (stand by)
Dimensions
17.25” (W) ×8.8” (H) ×19” (D) mm
Weight
107 lbs. Net 175 lbs shipping
