3. PREPARING FOR INSTALLATION
3.1 System Requirements
Ethernet Cables to connect the XGS-1008 to Ethernet enabled devices
Power should be AC 100-240V~ 0.1A(Max) 50/60Hz.
3.2 Installation Requirements
Install the XGS-1008 in a stable/safe place to avoid any possible damage
Inspect the AC power cord to ensure that it is correctly connected and
undamaged
To avoid electric shock, DO NOT open the XGS-1008 housing (no user service-
able parts inside). Opening the XGS-1008 will void your warranty.
It is recommended that the Grounding connection to the outlet is functioning
properly and the XGS-1008 is positioned away from direct sun light
Ensure there is suffi cient space around the XGS-1008 for proper ventilation and
heat dissipation. It is recommended to have at least 4-6 inches around all sides.
3.3 Before Connecting to the Network
Before connecting the XGS-1008 to the network, please check the following:
Determine placement location. Do not place any heavy articles on the XGS-1008.
Ensure there is adequate space for proper heat dissipation and ventilation around
the XGS-1008.
Power socket should be within 4 feet of the XGS-1008.
Check power adapter to confi rm safe and secure connection.
4. XGS-1008 INSTALLATION
4.1 Connecting Devices
Use standard Ethernet CAT5, CAT5e or CAT6 cable to connect the XGS-1008 to
a device as described below (CAT6 must be used in order to achieve full Gigabit
bandwidth). The XGS-1008 will automatically adjust to the characteristics (speed/
duplex) of the device to which it is connected.
