OPERATORS MANUAL
TRANSMISSION
GENERAL
Power transmission from engine happens trough clutch, variator
belt and driven variator to the gearbox or chainbox. Both clutch and
driven variator have a fixed and movable pulley. There is no
chain in gearbox.
DRIVE BELT REMOVAL AND INSTALLATION
· Remove the ignintion wires on spark plugs.
· Remove the variator cover.
· Take the belt as shown in the picture and pull strong upward
so that the pulleys of driven variator are parting.
On somes models, open the driven pulley with the drive belt
installer/remover (P/N 529019500) provided in tool box. Screw
tool in the threaded hole and tighten to open the pulley. Remove
the belt.
· Turn off the belt from the driven variator pulleys.
· Remove the belt from the clutch.
· Set the new belt on clutch and turn in on the driven variator
(gear in neutral).
· Put the variator cover in its place.
· Fasten the ignition wires.
NOTE: Driven variator is opened easier if the moving pulley is pulled
from the upper edge backward.
IMPORTANT! A new belt requires at least a 25 kms running-in
period before it can be loaded in full.
