OPERATORS MANUAL ____________________________________ 37
ENGLISH
IBC-CLUTCH
Function of the clutch is based on the sliding of the weight blocks (3 pcs) towards the
adjusting cup.
The clutch must be clean off from belt dust and other foreign particles according to the
service instructions.Under very hard circumstances even more often. Service and
maintenence of the IBC-clutch must be carried out by an authorized LYNX dealer/work
shop.
IBC-clutch Position of weights
TRA-clutch maintenance
The clutch is factory adjusted to provide the best performance under most riding conditions.
However certain conditions, such as deep snow, high altitude, pulling load, etc. may require
a different adjustment. Contact the authorized dealer for adjustment. The drive pulley
must be inspected and cleaned by an authorized LYNX- dealer/work shop at least annually.
