CONTROLS, INSTRUMENTS AND EQUIPMENT
Upper Body Module Installation
1. At front, insert the upper body module tabs into the bottom pan
openings.
2. Lower the rear end of the upper body module.
NOTE: Make sure the air intake duct is positioned correctly in the
boot.
3. Tighten air intake duct clamp.
4. On both sides, install th e upper body module retaining screws.
5. Install th e hood.
TIGHTENING TORQUE
Upper body screws
2.3 N•m ± 0.2 N•m
(20 lbf•in ±2lbf•in)
6. Connect the manifold air pressure and temperature sensor
(MAPTS) connector.
7. Connect the headlight conn ectors.
8. Install the storage compartment but leave the cover open.
9. Install gauge, secure with the screws.
TIGHTENING TORQUE
Gauge screws
2.3 N•m ± 0.2 N•m
(20 lbf•in ±2lbf•in)
10. Install the side panels.
Side Panels
WARNING
Never operate engine with side panels op ened or removed
from vehicle.
Side Panels Opening and Closing
Release all latches, then open panel.
_________________
105
