About the Tool
OFFSET is the distance that the blade tip is displaced from the center-line of the blade.
Protrusion Length of the Blade
Length of protrusion = t1 + t 2/ 2, but for your convenience you may just make it about 0.3~ 0.5 mm beyond the
blade holder tip.
Blade
Blade tip
Offset
Central line
Thickness of the
fi lm (t1)
Protrusion length
of the blade
Thickness of the
base paper (t2)
A. About the Tool III
