Lynx S-60 - PlaceholderHeading4; Blade Installation Procedure

Step 9
• The complete picture will be like Figure 2-9.
Figure 2-9
2.3 Blade Installation
Figure 2-10 is the illustrator of the blade holder. Insert a blade into the bottom of the blade holder and remove
the blade by pushing the pin. Make sure that your fi ngers are away from the blade tip.
Figure 2-10
Adjustment depth knob
Pin
Outward ring
2. Installation 2-6
