EM-6485-B Rev.21 P. 20 / 52
ADDR. WORD PARAMETER UNIT
6455 1 IN AVG - Average (demand) neutral current : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6456 1 IN AVG - Average (demand) neutral current : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6457 1 IN AVG - Average (demand) neutral current : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6459 2 P AVG - Average (demand) active power : High setpoint
Factory setting : 0
W
6461 2 P AVG - Average (demand) active power : Low setpoint
Factory setting : 0
W
6463 1 P AVG - Average (demand) active power : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6464 1 P AVG - Average (demand) active power : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6465 1 P AVG - Average (demand) active power : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6467 2 Q AVG - Average (demand) reactive power : High setpoint
Factory setting : 0
var
6469 2 Q AVG - Average (demand) reactive power : Low setpoint
Factory setting : 0
var
6471 1 Q AVG - Average (demand) reactive power : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6472 1 Q AVG - Average (demand) reactive power : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6473 1 Q AVG - Average (demand) reactive power : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6475 2 S AVG - Average (demand) apparent power : High setpoint
Factory setting : 0
VA
6477 2 S AVG - Average (demand) apparent power : Low setpoint
Factory setting : 0
VA
6479 1 S AVG - Average (demand) apparent power : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6480 1 S AVG - Average (demand) apparent power : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
