EM-6485-B Rev.21 P. 19 / 52
ADDR. WORD PARAMETER UNIT
6425 1 S - Apparent power : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6427 2 PF - Power factor : High setpoint
Factory setting : 0
1/10 000
6429 2 PF - Power factor : Low setpoint
Factory setting : 0
1/10 000
6431 1 PF - Power factor : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6432 1 PF - Power factor : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6433 1 PF - Power factor : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6435 2 F - Frequency : High setpoint
Factory setting : 6500
Hz/100
6437 2 F - Frequency : Low setpoint
Factory setting : 4500
Hz/100
6439 1 F - Frequency : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6440 1 F - Frequency : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6441 1 F - Frequency : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6443 2 I1 AVG thr. I3 AVG - Average (demand) current : High setpoint
Factory setting : 0
mA
6445 2 I1 AVG thr. I3 AVG - Average (demand) current : Low setpoint
Factory setting : 0
mA
6447 1 I1 AVG thr. I3 AVG - Average (demand) current : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6448 1 I1 AVG thr. I3 AVG - Average (demand) current : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6449 1 I1 AVG thr. I3 AVG - Average (demand) current : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6451 2 IN AVG - Average (demand) neutral current : High setpoint
Factory setting : 0
mA
6453 2 IN AVG - Average (demand) neutral current : Low setpoint
Factory setting : 0
mA
