EM-6485-B Rev.21 P. 15 / 52
ADDR. WORD PARAMETER
6116 1 Discrete input contact type
0 : Normally open contact (*)
1 : Normally closed contact
6117 1 Discrete output 2 function
0 : Undefined (*)
1 : Energy count
2 : Alarm
6118 1 Discrete output 2 contact type
0 : Normally open contact (*)
1 : Normally closed contact
The contact opens at the power OFF regardless of this setting.
6121 1 Discrete output 3 function
0 : Undefined (*)
1 : Energy count
2 : Alarm
6122 1 Discrete output 3 contact type
0 : Normally open contact (*)
1 : Normally closed contact
The contact opens at the power OFF regardless of this setting.
6125 1 Discrete output 4 function
0 : Undefined (*)
1 : Energy count
2 : Alarm
6126 1 Discrete output 4 contact type
0 : Normally open contact (*)
1 : Normally closed contact
The contact opens at the power OFF regardless of this setting.
(*) Factory setting
■ ENERGY SETTING DO
ADDR. WORD PARAMETER UNIT
6241 1 Energy count 1 assigned to the discrete output 1
Refer to the table in the following page.
—
6242 2 Pulse weight for Energy count 1
0 : No pulse output (disabled)
1 to 100 000 : Specified value × 0.1 (kWh / kvarh / kVA)
Factory setting : 10
kWh/10
kvarh/10
kVA/10
6244 1 Pulse duration (width) for Energy count 1
1 to 20 : Specified value × 100 msec.
Factory setting : 1
sec/10
6245 1 Tariff setting for Energy count 1
0 : Disable (*)
1 : Enable
—
6246 1 Energy count 2 assigned to the discrete output 2
Refer to the table in the following page.
—
6247 2 Pulse weight for Energy count 2
0 : No pulse output (disabled)
1 to 100 000 : Specified value × 0.1 (kWh / kvarh / kVA)
Factory setting : 10
kWh/10
kvarh/10
kVA/10
6249 1 Pulse duration (width) for Energy count 2
1 to 20 : Specified value × 100 msec.
Factory setting : 1
sec/10
6250 1 Energy count 3 assigned to the discrete output 3
Refer to the table in the following page.
—
6251 2 Pulse weight for Energy count 3
0 : No pulse output (disabled)
1 to 100 000 : Specified value × 0.1 (kWh / kvarh / kVA)
Factory setting : 10
kWh/10
kvarh/10
kVA/10
6253 1 Pulse duration (width) for Energy count 3
1 to 20 : Specified value × 100 msec.
Factory setting : 1
sec/10
