EM-6485-B Rev.21 P. 16 / 52
ADDR. WORD PARAMETER UNIT
6254 1 Energy count 4 assigned to the discrete output 4
Refer to the table in the following page.
—
6255 2 Pulse weight for Energy count 4
0 : No pulse output (disabled)
1 to 100 000 : Specified value × 0.1 (kWh / kvarh / kVA)
Factory setting : 10
kWh/10
kvarh/10
kVA/10
6257 1 Pulse duration (width) for Energy count 4
1 to 20 : Specified value × 100 msec.
Factory setting : 1
sec/10
(*) Factory setting
■ ENERGY COUNT TYPE
SET VALUE ID PARAMETER
0 T-EP Active energy, incoming (*)
1 T-EQ Reactive energy, LAG
2 T-ES Apparent energy
3 T-EP– Active energy, outgoing
4 T-EQ– Reactive energy, LEAD
5
6
T-EQ+LAG
T-EQ+LEAD
Reactive energy, incoming, LAG
Reactive energy, incoming, LEAD
7
8
T-EQ–LAG
T-EQ–LEAD
Reactive energy, outgoing, LAG
Reactive energy, outgoing, LEAD
9 — Reserved. DO NOT USE.
10
11
T-EQ+P
T-EQ–P
Reactive energy, incoming
Reactive energy, outgoing
2.00
2.00
12 — Reserved. DO NOT USE.
13 T-EQA Active energy, (incoming + outgoing)
2.00
200 EP Active energy, high tariff, incoming
2.00
201 EQ Reactive energy, high tariff, LAG
2.00
202 ES Apparent energy, high tariff
2.00
203 EP– Active energy, high tariff, outgoing
2.00
204 EQ– Reactive energy, high tariff, LEAD
2.00
205
206
EQ+LAG
EQ+LEAD
Reactive energy, high tariff, incoming, LAG
Reactive energy, high tariff, incoming, LEAD
2.00
2.00
207
208
EQ–LAG
EQ–LEAD
Reactive energy, high tariff, outgoing, LAG
Reactive energy, high tariff, outgoing, LEAD
2.00
2.00
209 — Reserved. DO NOT USE.
210
211
EQ+P
EQ–P
Reactive energy, high tariff, incoming
Reactive energy, high tariff, outgoing
2.00
2.00
212 — Reserved. DO NOT USE.
213 EQA Reactive energy, high tariff, (incoming + outgoing)
2.00
300 L-EP Active energy, low tariff, incoming
2.00
301
302
L-EQ
L-ES
Reactive energy, low tariff, LAG
Apparent energy, low tariff
2.00
2.00
303 L-EP– Active energy, low tariff, outgoing
2.00
304 L-EQ– Reactive energy, low tariff, LEAD
2.00
305
306
L-EQ+LAG
L-EQ+LEAD
Reactive energy, low tariff, incoming, LAG
Reactive energy, low tariff, incoming, LEAD
2.00
2.00
307
308
L-EQ–LAG
L-EQ–LEAD
Reactive energy, low tariff, outgoing, LAG
Reactive energy, low tariff, outgoing, LEAD
2.00
2.00
309 — Reserved. DO NOT USE.
310
311
L-EQ+P
L-EQ–P
Reactive energy, low tariff, incoming
Reactive energy, low tariff, outgoing
2.00
2.00
312 — Reserved. DO NOT USE.
313 L-EQA Reactive energy, low tariff, (incoming + outgoing)
2.00
