EM-6485-B Rev.21 P. 22 / 52
ADDR. WORD PARAMETER UNIT
6511 1 THD U1N thr. THD U3N - Phase voltage total harmonic distortion : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6512 1 THD U1N thr. THD U3N - Phase voltage total harmonic distortion : Hysteresis (dead-
band)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6513 1 THD U1N thr. THD U3N - Phase voltage total harmonic distortion : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6515 2
UT12 thr. UT31 - Phase angle between phase voltages : High setpoint 2.00
Factory setting : 0
°
6517 2
UT12 thr. UT31 - Phase angle between phase voltages : Low setpoint 2.00
Factory setting : 0
°
6519 1 UT12 thr. UT31 - Phase angle between phase voltages : Alarm output 2.00
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6520 1
UT12 thr. UT31 - Phase angle between phase voltages : Hysteresis (deadband) 2.00
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6521 1
UT12 thr. UT31 - Phase angle between phase voltages : ON delay time 2.00
0 to 999 : Seconds
Factory setting : 0
Seconds
(*) Factory setting
