■ LCD SETTING
ADDR. WORD PARAMETER
6625 1 LCD backlight operating mode (The backlight turns on regardless of this setting in case of alarms/errors.)
0 : AUTO (*) ON at alarm and operating;
OFF after the OFF TIMER time has been elapsed after the last operating.
1 : ON Continuously ON
2 : OFF Continuously OFF
6626 1 LCD backlight OFF timer
1 to 999 : Seconds
Time to be elapsed after the last operating before the backlight is turned off.
Factory setting : 600
6627 1 LCD backlight brightness
1 to 3
(dark) 1 << brightness >> 3 (bright)
Factory setting : 2
6628 1
LCD update rate 2.00
0 to 60 : Seconds
Display data updating rate. Set ‘0’ for the maximum possible rate.
Factory setting : 0
(*) Factory setting
■ LCD BARGRAPH SETTING
The bargraph is indicated proportionally to the specified rating (100%). For the energy values, it indicates [Current × Voltage] as
100%.
ADDR. WORD PARAMETER UNIT
6753 1 Current 100%
1 to 20 000 : Current (A)
Factory setting : 1 or 5
A
6754 2 Voltage 100%
1 to 400 000 : Voltage (V)
Factory setting : 300
V
■ ‘MY DEFAULT’ SETTING
Custom default view setting.
ADDR. WORD PARAMETER UNIT
6881 1 ‘My default’ time
0 : Disable (*)
1 to 999 : Seconds
The display returns to the preset view if the control keys are untouched for the preset time.
Seconds
6882 1
‘My default’ data display view
Shows the parameter set displayed on ‘My default’ view.
-1 : Automatic cyclic switching of ∑1 through ∑4 as ‘My default’ view. 2.00
—
6883 1 ‘My default’ energy display view
Shows the parameter type displayed on the bottom data display.
—
6884 1 ‘My default’ energy reading display unit
0 : 0.1 kWh, 0.1 kvarh, 0.1 kVA (*)
1 : 0.1 Wh, 0.1 varh, 0.1 VA
Shows the unit (factor) of the parameter on the energy display (k = kilo).
—
(*) Factory setting
