M-system 53U User Manual

53U
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
EM-6485-B Rev.21 P. 4 / 52
COMPONENT IDENTIFICATION
■ FRONT VIEW ■ REAR VIEW
Data Displays
Control Buttons
Current Input
Te rminals
Configurator
Jack
Auxiliary Power
Supply Terminals
Ext. Interface
Te rminals
Voltage Input
Te rminals
∑ IU PQS MAXE PRGPF THD
ENTER ESCAPE
■ CONTROL BUTTON OPERATIONS
∑
IU
PQS
MAX
E PRG
PF THD
ENTER
ESCAPE
E PRG ESCAPE
E PRG ESCAPE
∑
∑
IU
+
+
PQS
PF THD
Hold down
IU Hold down
Hold down
Hold down
Hold down
Hold down
NORMAL MODE
Indicates
∑ values
Indicates Voltage or Current
Indicates Power
Indicates Power Factor or THD
Indicates totalized values
(max., min., average/demand)
Switches Energy readings
Switches to My Default mode
Switches to PC Configuration mode
Switches to Setting mode
Indicates Harmonics by degrees
Switches Energy reading units
Indicates the shortcut menu
SETTING MODE
Go Left
Go Right
Go Down
Go Up
Selects menu; Enables setting changes
Cancels setting changes
----
----
----
----
----
----
BUTTON OPERATION
FUNCTIONS
■ HOW TO CHANGE VALUES (e.g. 5.000A to 150.0A)
PF THD
press
button
3 times
∑
press
button
5 times
PQS
press
button
once
∑
press
button
once
∑
press
button
once
PF THD
press
button
5 times
Press to increase or decrease the value.
Press to move between digits.
Pressing at the leftmost digit shifts the value on display to the right by 1 digit.
The decimal point and unit are also switched to appropriate ones.
IU
PQS PF THD
∑
∑
