EM-6485-B Rev.21 P. 21 / 52
ADDR. WORD PARAMETER UNIT
6481 1 S AVG - Average (demand) apparent power : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6483 2 THD I1 thr. THD I3 - Current total harmonic distortion : High setpoint
Factory setting : 0
%/10
6485 2 THD I1 thr. THD I3 - Current total harmonic distortion : Low setpoint
Factory setting : 0
%/10
6487 1 THD I1 thr. THD I3 - Current total harmonic distortion : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6488 1 THD I1 thr. THD I3 - Current total harmonic distortion : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6489 1 THD I1 thr. THD I3 - Current total harmonic distortion : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6491 2 THD IN - Neutral current total harmonic distortion : High setpoint
Factory setting : 0
%/10
6493 2 THD IN - Neutral current total harmonic distortion : Low setpoint
Factory setting : 0
%/10
6495 1 THD IN - Neutral current total harmonic distortion : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6496 1 THD IN - Neutral current total harmonic distortion : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6497 1 THD IN - Neutral current total harmonic distortion : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6499 2 THD U12 thr. THD U31 - Delta voltage total harmonic distortion : High setpoint
Factory setting : 0
%/10
6501 2 THD U12 thr. THD U31 - Delta voltage total harmonic distortion : Low setpoint
Factory setting : 0
%/10
6503 1 THD U12 thr. THD U31 - Delta voltage total harmonic distortion : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6504 1 THD U12 thr. THD U31 - Delta voltage total harmonic distortion : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6505 1 THD U12 thr. THD U31 - Delta voltage total harmonic distortion : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6507 2 THD U1N thr. THD U3N - Phase voltage total harmonic distortion : High setpoint
Factory setting : 0
%/10
6509 2 THD U1N thr. THD U3N - Phase voltage total harmonic distortion : Low setpoint
Factory setting : 0
%/10
