■ ALARM SETTING
ADDR. WORD PARAMETER UNIT
6369 1 Power ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6370 1 Latching
0 : No latching (*)
1 : Latching (Alarm trip is held until a reset command is received or power OFF)
—
6371 2 I1 thr. I3 - Current : High setpoint
Factory setting : 0
mA
6373 2 I1 thr. I3 - Current : Low setpoint
Factory setting : 0
mA
6375 1 I1 thr. I3 - Current : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6376 1 I1 thr. I3 - Current : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6377 1 I1 thr. I3 - Current : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6379 2 IN - Neutral current : High setpoint
Factory setting : 0
mA
6381 2 IN - Neutral current : Low setpoint
Factory setting : 0
mA
6383 1 IN - Neutral current : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6384 1 IN - Neutral current : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6385 1 IN - Neutral current : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6387 2 U12 thr. U31 - Delta voltage : High setpoint
Factory setting : 0
V/100
6389 2 U12 thr. U31 - Delta voltage : Low setpoint
Factory setting : 0
V/100
6391 1 U12 thr. U31 - Delta voltage : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6392 1 U12 thr. U31 - Delta voltage : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6393 1 U12 thr. U31 - Delta voltage : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6395 2 U1N thr. U3N - Phase voltage : High setpoint
Factory setting : 0
V/100
