EM-6485-B Rev.21 P. 18 / 52
ADDR. WORD PARAMETER UNIT
6397 2 U1N thr. U3N - Phase voltage : Low setpoint
Factory setting : 0
V/100
6399 1 U1N thr. U3N - Phase voltage : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6400 1 U1N thr. U3N - Phase voltage : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6401 1 U1N thr. U3N - Phase voltage : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6403 2 P - Active power : High setpoint
Factory setting : 0
W
6405 2 P - Active power : Low setpoint
Factory setting : 0
W
6407 1 P - Active power : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6408 1 P - Active power : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6409 1 P - Active power : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6411 2 Q - Reactive power : High setpoint
Factory setting : 0
var
6413 2 Q - Reactive power : Low setpoint
Factory setting : 0
var
6415 1 Q - Reactive power : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6416 1 Q - Reactive power : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
6417 1 Q - Reactive power : ON delay time
0 to 999 : Seconds
Factory setting : 0
Seconds
6419 2 S - Apparent power : High setpoint
Factory setting : 0
VA
6421 2 S - Apparent power : Low setpoint
Factory setting : 0
VA
6423 1 S - Apparent power : Alarm output
0 : Disable (*)
1 : Display only
2 : Display + discrete output 1
3 : Display + discrete output 2
4 : Display + discrete output 3
5 : Display + discrete output 4
—
6424 1 S - Apparent power : Hysteresis (deadband)
0 to 999 : Specified value × 0.1 (%)
Factory setting : 0
%/10
