■ DISCRETE I/O DO DI
ADDR. WORD PARAMETER
3073 1 Discrete input status
3105 1 Discrete output 1
The discrete output status can be changed by writing at this address from the host if no function is assigned.
3106 1 Discrete output 2
The discrete output status can be changed by writing at this address from the host if no function is assigned.
3107 1 Discrete output 3
The discrete output status can be changed by writing at this address from the host if no function is assigned.
3108 1 Discrete output 4
The discrete output status can be changed by writing at this address from the host if no function is assigned.
■ ANALOG OUTPUT AO
ADDR. WORD PARAMETER UNIT
3137 1 Analog output 1
Reads the present analog output value.
The output value can be changed by writing at this address from the host if no function is
assigned.
mA/100 or mV
3138 1 Analog output 2
Reads the present analog output value.
The output value can be changed by writing at this address from the host if no function is
assigned.
mA/100 or mV
3139 1 Analog output 3
Reads the present analog output value.
The output value can be changed by writing at this address from the host if no function is
assigned.
mA/100 or mV
3140 1 Analog output 4
Reads the present analog output value.
The output value can be changed by writing at this address from the host if no function is
assigned.
mA/100 or mV
