■ DIAGNOSTICS
ADDR. WORD PARAMETER UNIT
9201 2 Received Modbus frames times
9203 2 Discarded Modbus frames times
9205 2 Responded Modbus frames times
9207 2 Responded Modbus Exception (error) frames times
9209 2 Detected Modbus Framing Error frames times
9211 2 Detected Modbus Overrun Error frames times
9213 2 Detected Modbus Parity Error frames times
9215 2 Detected Modbus CRC Error frames times
9217 2 Processing delays times
9219 2 Processing delay sequence number No.
■ DEVICE INFORMATION
ADDR. WORD PARAMETER
9601 1 Device ID
5301 : 53U
9602 1 Device Version No.
Version No. = (No. × 100). e.g. Version 1.00 = 100
9603
9604
9605
9606
4 Serial No. Upper digit: 2nd character
Upper digit: 4th character
Upper digit: 6th character
Upper digit: 8th character
Lower digit: 1st character
Lower digit: 3rd character
Lower digit: 5th character
Lower digit: 7th character
9607
9608
9609
9610
9611
9612
9613
9614
8 Tag No. Upper digit: 2nd character
Upper digit: 4th character
Upper digit: 6th character
Upper digit: 8th character
Upper digit: 10th character
Upper digit: 12th character
Upper digit: 14th character
Upper digit: 16th character
Lower digit: 1st character
Lower digit: 3rd character
Lower digit: 5th character
Lower digit: 7th character
Lower digit: 9th character
Lower digit: 11th character
Lower digit: 13th character
Lower digit: 15th character
This register can be written in.
9623 1
Extension function 2.00
An addition of the following numbers are read out to identify the external interface type.
0001 : Analog output 4 – 20 mA DC
0002 : RS-485 (Modbus RTU)
0004 : Analog output 1 – 5 V DC
0008 : Discrete output 110 V DC
9624 1 Numbers of Di 2.00
0 : None
1 : 1 point
9625 1
Numbers of Do 2.00
0 : None
1 thr. 4 : 1 thr. 4 points
9626 1
Numbers of Ao 2.00
0 : None
1 thr. 4 : 1 thr. 4 points
