M3 Mobile BLACK - Wireless LAN

31
3.6 Wireless LAN
3.6.1 WLAN configuration(Summit 30AG)
How to connect
WLAN icon ( / ) on task bar indicates with WLAN is on or off respectively. If WLAN is off,
click on the icon and Select ‘Turn on WIFI’ to turn on WLAN module. Then, WLAN status icon
( ) will appear on the task bar. Click on the icon to launch Summit Client Utility (SCU).
To connect to an AP, follow steps below.
i. Choose ‘Scan’ from ‘Profile’ tab of SCU.
ii. From the AP list, click on the target SSID and Configure to access. Enter secure codes
if applicable.
