DMX-Output / Input
The DMX input is protected against over-voltage with additional suppressor diodes and complies with
the RS485 or RS 422a standard.
The OUT C DMX output (Thru 1) is connected 1:1 (pins 1 through 3) with the (IN 1) DMX input. Same
applies to OUT D (Thru 2) with (IN 2).
Pin assignment: pin 1 = earth (not connected to ground)
pin 2 = Data - pin 4 = not assigned
pin 3 = Data + pin 5 = not assigned
Please note that all DMX devices are connected “in series” and that you cannot build y connections.
The DMX line has to be terminated by a 100 terminal resistance between pin 2 and 3.
Make the settings for DMX address etc. in the respective menus..
Data sheet
Dimensions: see chapter 6
Weight: Flush mount version 0,160 kg without accessories
Rig mount touring version 1,100 kg without accessories
Power supply: Flush-mount Version:
PowerOverEthernet, no additional supply necessary
Rigg-mount Version:
PowerOverEthernet and
100 - 240 V AC , 50 - 60 Hz (no switch over necessary)
Power consumption: approx. 2 Watt (in PowerOverEthernet - mode)
approx. 15 Watt (Rig-mont version with external power supply)
Fuse: T1A , L 250V (only Rig-mount Version)
