MA lighting 2-Port Node - Examples of Use

MA Lighting Technology GmbH
.
Dachdeckerstr. 16
.
D-97297 Waldbüttelbrunn
66
66
6
Example of use 1
DMX A -out / in (512 parameter)
DMX B -out / in (512 parameter)
Switch / hub
100 Mbit
Installation:
The network must be of a 100Mbit type.
Options:
Output: 2x512 parameters / 2 Universes max. (i.e.
all channels output must be patched in the two
Universes.)
DMX A -OUT / IN (512 parameter)
DMX B -IN (512 parameter)
Switch / hub
100 Mbit
Example of use 2
Examples of use
Example of use 3
