Quick Start:
These are the basic steps to start up the 2-Port Node:
Mount the 2-Port Node (flush-mount version) in a flush box; install the rig-mounted version using the
fastening screws)
see page 19
Power supply:
Flush-mount: For this version, the switch / hub must support the PowerOnEthernet function
and must deliver sufficient power (approx. 2 Watt) - not for onPC!
Rig-mount: Either operate it via PowerOverEthernet and/or plug the supplied mains cord
into the 2-Port and connect it to a correctly installed wall socket (100-230V, 50-60Hz). You
can work with both operation modes simultaneously – no need to define or select any; on
power failure, the 2-Port will automatically switch over to the available power source.
Install onPC on a PC or laptop computer
or
Switch on the grandMA console
Connect the 2-Port using a network cable (RJ45 plug). Either via the switch / hub or by directly
plugging it into a PC or laptop computer (not valid for flush-mount version) - - no cross-cable!
Start a session from the console or in onPC
On the console / onPC open the TOOLS / MA NETWORK CONFIGURTAIONS / 2 PORT menu.
If needed, set the software version – if the „Version“ cell is highlighted in red,
see page 18
Set the IP-address of the 2-Port Node (press the SHOW ALL button). If there are several 2-Port
Nodes on the network, you can find each of them using the IDENTIF button – the display and the
LED of the selected Node will blink);
see page 11
Name the 2-Port (optional)
Set the MA NET or ARTNET mode
Set the session ID (only MANET) - must be identical to the one set on the console or in onPC
Set the ports,
see page 12
Connect the DMX cables
