80
50 mm min.
to a wall
3000 mm min.
to any obstacle
200 mm min.
to ceiling
2500 mm min. from floor
250 mm
min.
50 mm min.
to a wall
500 mm min.
to any obstacle
250 mm min.
from air inlet
to a wall
500 mm min. distance
from air outlet to a wall
250 mm min.
distance from
air inlet to a wall
Important: The appliance must be installed in accordance with the
national electrical code.
installation instructions
• These illustrations work as a guide only, they may not match the
external appearance of the unit you purchased.
• The installation must be carried out in accordance with national
electrical regulations and by authorized personnel only.
