Advanced configuration of the unit
User interface via web browser
The web interface allows you to fully congure the MACunit through an Ethernet connec-
tion and a web browser.
NOTE
To display the graphics provided in the unit conguration program correctly, we
recommend installing the web browser Mozilla Firefox 1.5 or higher (www.mozilla.
com) in the control PC.
NOTE
Cookies and Javascript must be enabled.
NOTE
Use a PC with an Ethernet network card and an Ethernet CAT-5E crossover cable.
1) Access the TCP/IP PROPERTIES of the PC and congure the following parameters:
F
IP ADDRESS OF THE PC: 192.168.1.1
F
SUBNET mASk: 255.255.255.0
2) Connect the PC to the LAN (RJ-45) port of the MAC unit (see number 11 on the dia-
gram in the section General description).
NOTE
The initial process must be made in local mode, although later you will be able to
access the unit from any PC in the LAN.
NOTE
The Ethernet connector of the MAChas two indicator lights:
J
The link is correct when the link LED (to the left of the Ethernet connector) is
lit.
J
There is activity in the link when the activity LED (to the right of the Ethernet
connector) is ashing.
3) Launch the web browser and enter the MAC unit's IP address:
F
INITIAL IP ADDRESS: 192.168.1.6
NOTE
This initial IP address may be modied by the user.
