Technical specifications
MAC models
Inputs
AV1 / AV2 /AV3 * / AV4 *
Format CVBS
Input level (video) Vpp 0,7 - 1,4
Input impedance Ω 75
Video standards PAL/SECAM/NTSC
Analogue / digital audio Yes / No
Input level (audio) Vpp 0,5 - 4,0
* Available only in MAC 401 model.
Output COFDM digital TV
COFDM standard DVB-T according to ETSI EN 300 744
Bandwidths MHz 6 / 7 / 8
Number of carriers 2K / 8K
MER dB 38 (typical)
Central frequency MHz 51 - 858
Level dBV 80
Output pitch attenuation dB 1
Impedance Ω 75
Frequency pitch kHz 1
Level adjustment dB -15
Frequency stability ppm ≤±30
Band aliasing dB ≤-50
Noise level (∆B = 8MHz) dBc ≤-70
Web user interface
Electric standard Ethernet 10BaseT
10/100Mbps
LAN connector RJ-45
Protocols HTTP / UDP
Operations
Mains voltage 230 - 240 V~
Consumption 0.45 A / 30 W
Operating temperature 0 to 45ºC
Mains connector IEC C8
