Before you start
Getting started...
GB
IE
Assembly
10
Check the chain tension using one hand to lift the saw chain >
(3) against the weight of the product. The correct chain tension
is achieved when the saw chain can be lifted by approximately
2 - 4 mm from the guide bar (4) in the centre (Fig. 12).
Chain ‘tie straps’
2-4 mm
Fig. 11
Fig. 12
Turn the locking wheel (6) to tighten the cover (8) completely >
(Fig. 10). Ensure the two latches snap into the grooves.
Fuel and engine oil
This product is equipped with a 2-stroke engine, the fuel and oil
tank are combined and it is essential to ll a fuel-oil mixture before
operating this product. Observe the technical specications for
suitable fuel and engine oil.
WARNING! This product is not supplied with fuel-oil
mixture in the engine! Before operating this product it is
essential to ll it with fuel-oil mixture!
40:1
