Your product
Before you start
31 32 33 34
35
1. Front handle
2. Front guard/chain brake
3. Saw chain
4. Guide bar
5. Sprocket nose
6. Locking wheel
7. Tension wheel
7a. Tension pin
8. Cover
9. Primer
10. Rear guard
11. Rear handle
12. Fixing screw
13. Air lter cover
14. Air lter
15. Spark plug connector
16. Cylinder ns
17. Oiling port
18. Spike bumper
19. Bolts
20. Chain catcher
21. Clutch
22. Drive sprocket
23. Recoil starter handle
24. Ignition switch (on/off)
25. Choke knob
26. Throttle interlock
27. Throttle trigger
28. Chain oil tank cap
29. Fuel tank cap
30. Air vents
31. Guide bar cover
32. Combination spanner/
Spark plug wrench
33. Chain le
34. Screwdriver
35. Bag
