MacAllister MCSP40 - Page 8

08
MCSP40 by MacAllister
Before you start
Getting started...
GB
IE
Assembly
Pull the guide bar (4) carefully towards the right to pre-tighten >
the saw chain (3) (Fig. 7).
Ret the cover (8) and slightly tighten the locking wheel (6) >
(Fig. 8). Make sure the tension pin (7a) is inserted into the lower
hole on the guide bar (Fig. 9).
START
6
7a
Fig. 8 Fig. 9
Saw chain tensioning
Always check the saw chain tension before use, after rst cuts
and regularly during use, approximately every ve cuts. After
initial operation, new chains can lengthen considerably. This is
normal during the break-in period and the interval between future
adjustments will lengthen quickly.
NOTE: The saw chain (3) has not yet been tensioned.
Tension the chain as described under “Saw chain
tensioning”. After operating the product for approximately
1 hour, adjust the chain tension again.
