MacDon 912 - Sickle and Sickle Drive Maintenance

Form # 46620 Issue 11/06
42
H
CO
NDITI
O
NER
U
NIVER
S
AL
S
HAFT
C
D
LEFT END RIGHT END
DRIVE SHAFT SUPPORT BEARINGS
E
F
LEFT END RIGHT END
CROSS-SHAFT END SUPPORT BEARINGS
DOUBLE SICKLE HEADER
LEFT END RIGHT END
REEL SHAFT BEARINGS & DRIVE CHAIN
922 & 933 HEADERS
G
H
MAINTENANCE/SERVICE
GREASING THE HEADER AND CONDITIONER
(continued)
100 Hours or Annually:
1. Hay Conditioner Universal Shaft (H)
- three fittings.
2. Drive Shaft Support Bearings (C) &
(D)
- two fittings
3. Cross-Shaft End Support Bearings
(E) & (F)
- two fittings on Double Sickle
Header
4. Reel Shaft Bearings (G) & (H)
- two fittings on 922 and 933
Headers
