Page 320
SPECIFICATIONS
CRANKSHAFT
Vibration Damper Hub to Crank Screw 360 490
Vibration Damper to Hub Screw 45 61
CYLINDER BLOCK
Main Bearing Capscrew (See “NOTE 2 — MAIN BEARING CAP
INSTALLATION” on page 328.)
210 285
Cylinder Block Main Brg. Cap Buttress Screw (See “NOTE 2 — MAIN
BEARING CAP INSTALLATION” on page 328.)
95 128
CYLINDER HEAD
Cylinder Head Capscrew* (See “NOTE 3 — CYLINDER HEAD TORQUING”
on page 328.)
205 278
Cylinder Head Cover Screw* 16 22
Inlet Manifold to Cyl. Head Screw 40 55
ELECTRONIC UNITS
EECU to Cyl. Block Mtg. Screw 31 42
EECU Isolating Studs 18 24
EECU Mounting Nuts 15 20
EECU Cooling Plate Screw 12 16
Electronic Unit Pump Terminal Screw 13 lb-in ± 2 lb-in 1.5 ± 0.2
Electronic Unit Pump to Cyl. Block Screw 42 57
FAN DRIVE
Fan Drive Pulley to Hub Screw 25 34
Poly-V Belt Tensioner Mounting Screw 40 55
FLYWHEEL, FLYWHEEL HOUSING AND CLUTCH
Flywheel Hsg. to Cylinder Block Screw 170 230
Flywheel to Crankshaft Screw 185 250
Clutch to Flywheel Mounting Screw 40 55
Transmission to Flywheel Hsg. Screw 40 55
FUEL SYSTEM
Fuel Filter Brkt. to Inlet Mfld. Screw 35 47
Fuel Supply Gallery Fitting Locknut 27 37
Fuel Return Gallery Ftg. (Check Valve) Locknut 27 37
Fuel Supply Pump to Cyl. Block Screw 40 55
INJECTOR NOZZLE AND NOZZLE FUEL INLET TUBE
Inj. Nozzle Holder Hold-Down Screw 45 61
Noz. Fuel Inlet Tube Clamp Screw to Cyl. Head 35 47
Noz. Fuel Inlet Tube Nut at Cylinder Head 25 34
Noz. Fuel Inlet Tube Nut at EUP 25 34
OIL COOLER – Bundle-Type
Oil Cooler Fitting to Water Pump Mounting Screw 60 81
Oil Cooler Oil Inlet and Outlet Tube Flange Mounting Screw 40 55
Oil Cooler/Oil Filter Fitting to Oil Filter Mounting Adapter Screw 40 55
Fastener Name
Torque
Lb-Ft N•m
