SPECIFICATIONS
Page 321
Oil Cooler Water Inlet and Water Outlet Ftg. to Oil Cooler Screw 20 27
OIL COOLER – Plate-Type
Oil Cooler Tube to Water Pump (MR Model Stud) 20 27
Oil Cooler Tube to Water Pump 40 55
Oil Cooler to Brkt. 20 27
Oil Cooler/Oil Filter Brkt. Fittings 1/4 NPT (Turbo, REPTO) 12 16
Oil Cooler/Oil Filter Brkt. to Cylinder Block 40 55
OIL FILTER
Centrifugal Oil Filter Drain Fitting Stud Nut 40 55
Centrifugal Oil Filter Mounting Adapter 150 203
Centri-Max Plus Spindle (LSR) 15 20
Centri-Max Plus Cover (LSR) 15 20
Oil Filter Pedestal to Cyl. Block Screw 60 81
Oil Filter Relief Valve Plunger Spring Cap 100 135
Oil Filter Adapter to Oil Cooler Brkt. Screw 40 55
OIL PAN
Oil Pan Drain Plug 55 75
Oil Pan to Cyl. Block Fastener (8 mm Screw) 23 31
Oil Pan to Cyl. Block Shoulder Bolt/Stud 15 20
OIL PUMP
Oil Pump Cover to Housing Screw 15 20
Oil Pump to Cyl. Block Mtg. Screw 40 55
Oil Pump Shaft Driven Gear Retaining Nut 60 81
Oil Pump Inlet Ftg. to Oil Pump Hsg. Screw 35 47
Oil Pump Pressure Relief Valve Cap 80 108
PISTON COOLING
Piston Cooling Nozzle to Cyl. Block Screw 15 20
SENSORS (FOR DASH DISPLAY)
Coolant Temp. (1/2 NPT, Side Mount on Water Manifold) 23 31
Oil Temp. (1/4 NPT, Mount on Oil Filter Pedestal 18 24
Oil Temp. (1/2 NPT, Side Mount on Oil Pan) 23 31
SENSORS (V-MAC III)
Ambient Air Temperature (1/2 NPT) 23 31
Boost Air Temperature (M16 x 2) 28 38
Coolant Temperature (3/8 NPT, Rear Mount on Water Manifold) 23 31
Fuel Temperature (3/8 NPT) 23 31
Oil Pressure (M10 x 1.5) 12 16
Engine Speed & Position (Flywheel Hsg. and Engine Front Cover) 7 10
TIMING GEAR COVER (ENGINE FRONT COVER)
Breather Mounting Screws 15 20
Timing Cover and Frt. Support Brkt. to Cyl. Block Screw 70 95
Fastener Name
Torque
Lb-Ft N•m
